Features
CUSTOM LAP BAR DESIGN
Oversized zero-turn lap bars with quick-adjust knobs, full-length comfort grips and integrated automatic parking brake system reduces operator fatigue.
BEST-IN-CLASS DECK
Tackle the toughest conditions with the industry-leading only triple-7-gauge steel cutting deck: a 7-gauge deck shell with 7-gauge top and bottom reinforcements. Designed for durability, our decks produce a quality cut you can always count on.
MAINTENANCE MADE EASIER
Slash downtime thanks to Cub Cadet’s new spindle design. Completely sealed, dual double-row ball bearings make the spindle maintenance-free for its lifetime, and anti-friction washers prevent self-tightening, making blade maintenance easier.
ALL-DAY COMFORT
The PRO Z has been engineered to absorb the punches so your body doesn’t have to. Our exclusive air-ride seat allows you to adjust seat firmness to your personal preference for a smooth ride all day long.
BEEFED-UP FRONT END
Absorb the impact of rough terrain with new front-end construction featuring a best-in-class combination of axle, hub and yoke size. With an isolation-dampening system and maintenance-free ball bearings, the PRO Z is designed to handle the rigors of the job.
Specifications
| STEERING |
| Lap Bar / Steering Wheel Adjustment: 3/4 length padded bars w/tooless quick adjust dial |
| CHASSIS |
| Rear Bumper: 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch |
| ROPS: 2" x 2" quick-latch tool-less foldable 3 position |
| Front Axle / Yokes: 2" x 3" solid steel with sealed ball bearings (e-coated) |
| Frame: Fully welded, full-length 3/8 x 5" laser cut steel / integrated tie-down slots |
| OPERATION |
| Seat Type: High-back dial suspension with EVC Cushion seat belt angle back adjust arm rests |
| Rear Tires: 24" x 12" - 12" (Turf Tread) |
| PTO Clutch: Warner Clutch - 125 ft lb. |
| Cruise Control: N/A |
| Throttle/PTO/Key Switch: HD Low-profile throttle lever, sealed key switch & electronic fingertip engagement pto |
| Front Tires: 13" x 6.5" - 6" (smooth) |
| Lap Bar / Steering Wheel Control: High Performance & Speed Control |
| Park Brake / Braking: Hand-operated lever with integrated hydro pump release lever |
| DIMENSIONS |
| L / W / H with discharge chute UP and ROPs DOWN: 80" L x 50" W x 50" H |
| Weight (approx): 1272 lbs. |
| MOWER DECK |
| Rolled Leading Edge Reinforcement: 1/4" (.250") steel |
| Top Reinforcement(s): 7ga. (.187") top plate |
| Deck Material: fabricated 7ga. (.187”) steel shell |
| Cutting Height: 1" - 5" |
| Deck Size/Type: 48" Fabricated Deck |
| Spindle Construction: 8" sealed cast aluminum housing (maintenance-free) |
| Leading Edge Reinforcement: 1/4" (.250") steel |
| Discharge Chute: High-density, impact-resistant rubber |
| Bottom Reinforcement: 7ga. (.187") bottom plate |
| Deck Blades: 3 high-lift Marbain® blades / 18,500 fpm (approx.) |
| Deck Height Adjustment: Foot pedal with spring assist 16 Positions |
| Side Construction: 5/16"(.313) steel on trim and discharge sides |
| Trim-Side Wear Guard: 3/4" Thick UHMW-PE Replaceable Trim-side Wear Guard |
| Anti-Scalping: 2 Front HD w/ Bushings & Grease Zerk |
| Deck Style/Construction: 7ga. top plate 7ga. bottom reinforcement ¼” rolled leading edge |
| GENERAL |
| Cup Holder: Intergrated into Side Pod |
| Hour Meter: Standard electronic |
| Engine & Drive System |
| Horsepower / CC's: 23.5hp - 726cc |
| Engine Type; Kawasaki FX FX730v |
| Ground Speed: Fwd: 10 mph/Rev: 5 mph |
| Fuel Capacity: Twin 7.45 gal. tanks (14.9 gal. total) with dial gauge |
| Transmission: Parker HTJ Series 12cc pump / 260cc wheel motor |
