Cub Cadet PRO Z 148 L EFI

Double tap to zoom



Features

CUSTOM LAP BAR DESIGN

Oversized zero-turn lap bars with quick-adjust knobs, full-length comfort grips and integrated automatic parking brake system reduces operator fatigue.

BEST-IN-CLASS DECK

Tackle the toughest conditions with the industry-leading only triple-7-gauge steel cutting deck: a 7-gauge deck shell with 7-gauge top and bottom reinforcements. Designed for durability, our decks produce a quality cut you can always count on.

MAINTENANCE MADE EASIER

Slash downtime thanks to Cub Cadet’s new spindle design. Completely sealed, dual double-row ball bearings make the spindle maintenance-free for its lifetime, and anti-friction washers prevent self-tightening, making blade maintenance easier.

ALL-DAY COMFORT

The PRO Z has been engineered to absorb the punches so your body doesn’t have to. Our exclusive air-ride seat allows you to adjust seat firmness to your personal preference for a smooth ride all day long.

BEEFED-UP FRONT END

Absorb the impact of rough terrain with new front-end construction featuring a best-in-class combination of axle, hub and yoke size. With an isolation-dampening system and maintenance-free ball bearings, the PRO Z is designed to handle the rigors of the job.

Specifications

STEERING
Lap Bar / Steering Wheel Adjustment:  3/4 length padded bars w/tooless quick adjust dial

CHASSIS
Frame:  Fully welded, full-legnth 12ga. channel frame with 14ga. reinforcements
Front Axle / Yokes:  2" x 3" solid steel and 3/8" thick steel with sealed ball bearing front yokes
Rear Bumper:  5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
ROPS:  2"x2" Foldable 3 Position Low Profile Clearance

DIMENSIONS
Length / Width / Height with chute down and ROPS up:  80" L x 61" W x 70" H
L / W / H with discharge chute UP and ROPs DOWN:  80" L x 49" W x 48" H
Weight (approx):  970 lbs.

ELECTRICAL SYSTEM
Battery Voltage:  230 cold crank amp
Alternator:  15 amp regulated

OPERATION
Park Brake / Braking:  Intergrated system in Lap Bars for ease of use
Lap Bar / Steering Wheel Control:  High Performance & Speed Control
Front Tires:  13" x 6.5" - 6" (smooth)
Rear Tires:  23" x 10.5" - 12" (Turf Master)
PTO Clutch:  Warner Clutch - 125 ft lb.
Seat Type:  High-back suspension with seat belt, adjustable arm rests and 6" seat travel
Cruise Control:  N/A
Safety Systems:  Operator presence

MOWER DECK
 Spindle Construction:  5" sealed cast aluminum housing (maintenance-free)
 Deck Material:  Fully welded 10ga. (.135") steel deck shell with reinforcements totaling .560"
 Discharge Chute:  High-density, impact-resistant rubber
 Top Reinforcement(s):  2ga. (.250") top plate
 Blade-Tip Speed (Approx):  18,500 fpm
 Deck Height Adjustment:  Hand Lever / 15 position / spring assist
 Side Construction:  5/16"(.313) steel on trim and discharge sides
Bottom Reinforcement:  7ga. (.175") steel
Trim-Side Wear Guard:  3/4" Thick UHMW-PE Replaceable Trim-side Wear Guard
Deck Blades:  3 high-lift Marbain® blades / 18,500 fpm (approx.)
Leading Edge Reinforcement:  1/4" (.250") steel
Spindle Covers:  Steel - Tooless Quick Release
 Deck Size/Type:  48" Fabricated Deck
 Cutting Height:  1" - 5"
 Deck Style/Construction:  Floating, fabricated 10ga. (.135”) steel shell (e-coated)
Anti-Scalping:  2 Front HD w/ Bushings & Grease Zerk

GENERAL
Cup Holder:  Intergrated into Side Pod
Hour Meter:  Standard electronic

Engine & Drive System
Fuel Capacity:  Twin tanks - 3.5 gallon ea. (7 gallon total) with oversized filler opening
Ground Speed:  9.5mph fwd. / 4.5mph rev.
Engine Type:  Kohler Confidant EFI EZT-740
Horsepower / CC's:  25hp - 747cc
 Transmission:  12cc Hydro-Gear® ZT 3400 with charge pumps
