Unbeatable in every environment.
The PRO HW™ has the thickest steel beam, control center and yokes in the industry. Paired with a higher ground clearance and superior weight balance, this commercial walk behind mower can easily maneuver over curbs while moving forward or in reverse and can follow any contour effortlessly thanks to a fixed floating deck.
Good things can come easy.
This machine is tough, but not on you. Easy-Trac steering hand levers use less force to steer the mower. Straight-line adjustable tracking allows for on-the-go straight line adjustments with the turn of a knob. The hydro drive system with cruise control gives you infinite speed control so you can mow at your own pace.
Minimize maintenance, maximize performance.
The PRO HW™ features a new spindle assembly, including completely sealed, single-row ball bearings that are maintenance-free, which means less downtime for you and your crew.
|Additional Frame Features: 1.5 x 3" fully welded tube|
|Front Axle / Yolks: Frame-mounted foot pedal front-end lift assist|
|Frame: Operator Tower with 7ga. Construction|
|Rear Bumper: N/A|
|Deck Blades: 3 high-lift Marbain® blades / 18,500 fpm (approx.)|
|Discharge Chute: High-density, impact-resistant rubber|
|Spindle Construction: 5" sealed cast aluminum housing (maintenance-free)|
|Bottom Reinforcement: 7ga. (.175") steel|
|Deck Height Adjustment: 4-pin manual with deck-mounted lift handles / 7 positions|
|Cutting Height: 1.5" - 4.5"|
|Deck Size/Type: 36" Fabricated Deck|
|Top Reinforcement(s): 7ga. top plate|
|Leading Edge Reinforcement: 7 ga.|
|Side Construction: 1 / 4" steel|
|Trim-Side Wear Guard: ¾" trim-side (polymer)|
|Deck Style/Construction: Fixed floating, fabricated 10ga. (.135”) steel shell|
|Front Tires: 11" x 4" - 5" smooth (run flat)|
|Cruise Control: N/A|
|Rear Tires: 18" x 6.5" - 8" (Turf Master)|
|PTO Clutch: Warner Clutch - 125 ft lb|
|Park Brake / Braking: Hand-operated lever|
|Lap Bar / Steering Wheel Control: Hand-lever steering control with ball bearing linkage for smooth feel|
|Additional Controls: Single-knob straight line tracking ajustment|
|Operator Controls: Single-lever cruise control (0-7 MPH)|
|Hour Meter: Standard electronic|
|ENGINE & DRIVE SYSTEM|
|Engine Type: Kawasaki FS481v (Recoil Start)|
|Horsepower / CC's: 14.5hp 603cc|
|Fuel Capacity: 5 gal.|
|Ground Speed: 7mph fwd. / 3mph rev.|
|Transmission: Hydro-Gear® ZT 2800 charged (commercial-grade)|
|Weight: 590 lbs.|
|Height (ROPS Down / Up): 45"|
|Width (Chute Up / Down): 38"/49"|
