Features
Performance Features
- Cutting widths from 60" to 84"
- Quick-Hitch Ready
- Gearbox Ratings up to 130 HP
- Taller Sidebands Increase Cutting Efficiency
Construction Features
- Taller Sidebands increase cutting volume & clipping efficiency
- 1/4” Skids run half the length of the cutter
- Rear Band is continuously welded and curved to add strength
- Formed Tailwheel Bracket is welded to the deck, providing strength
- Puncture-proof laminated tailwheels
- Quick Hitch compatibility
Safety Features
- PTO Shield
- Front Deflector
- Rear Metal Band
- Front Chains
- Rear Chains
Specifications
Model | BH317 |
Cutting Width (in) | 84 |
Cutting Height (in) | 2-12 |
Cutting Capacity (in) | 3 |
Hitch Type | Cat 2 or 3 Std & QH |
Deck Thickness (ga) | 10 |
Sidebands | 11-3/4" x 10 ga |
Driveline | ASAE Cat 4 |
Driveline Protection | Slip-Clutch |
Gearbox Rating (PTO) | 130 |
Tractor PTO Speed | 540 |
Minimum Tractor HP | 55 |
Blade Holder | Round |
Blades (in) | 1/2 x 4 uplift |
Blade Tip Speed (FPM) | 14,450 |
Tires | Single or Dual 16" Laminated |
Safety Shielding | Front and Rear Deflectors or Chains |
Approximate Weight (lbs) | 1051 |
Warranty | 6Year Gearbox Warranty and 1 Year Limited Machine Warranty |
Color | Available in Red, Green, Orange, Blue |
