Features

ATTRACTIVE, VISIBILITY ENHANCING DESIGN

The curved design of the loader beam means that the X-series matches today’s modern tractors perfectly. The fact that it has the lowest knee placement on the market also means that is has superb side visibility.

VISIBILITY ABOVE ALL

There are no hoses or pipes that block visibility. With the X-series, you are getting the best possible visibility, even in the dark because the low placement of the cross tube does not block the tractor lights.

PROTECTIVE HOSE COVER

Yet another reliability-ensuring detail - protecting the hydraulic hoses from unnecessary wear.

CONVENIENT AUTOMATIC IMPLEMENT LOCKING

Yet another smart safety function that ensures the implement is always correctly attached and that the locking pins are always in the locked position. Locking is automatic when crowding back the tool carrier.

QUICK AND SIMPLE TO CONNECT AND DISCONNECT

No tools are needed to disconnect your X-series loader. The sturdyand integrated support legs further simplify connection and disconnection.

UNIQUE CONCEPT FOR IMPLEMENT CHANGES

The fact that the tool carrier can be tilted forward almost 180° provides optimum control and free visibility of the implement hook from inside the cabin. Simple and beneficial for both safety and productivity.

ALWAYS KEEPS THE GREASE IN PLACE

All of the pins have a rubber washer and a spring washer, which prevents axial play, secures the pin on both sides and keeps the grease in place.

IMPLEMENT ANGLE INDICATOR

The compact implement angle indicator is easily adjusted for different implements and offer settings for 3 different implements at the same time. Use it for easy implement angle reference relative to the ground.

EXTREMELY STRONG SUBFRAME AND BEARING BOX

The heavy-duty dimensions of the subframe are the same as on our world-leading Q-series loaders. together with the inwardly curved design of the bearing box, this gives the X-series loader significant torsional rigidity and stability.

Specifications

Lift heights and bucket angles
Maximum Lift Height - Measured at Pivot Pin (m) 3.40
Maximum Lift Height - Under Level Bucket (m) 3.20
Maximum Dump Angle at Maximum height° (Degrees) 50
Maximum Q Level angle° (Degrees) N/A
Maximum Rollback Angle at ground° (Degrees) 44
Loader forces
Lift Capacity to Maximum Height -800mm From Pivot Pin (kg) 1520
Lift Capacity, 1,5m Height -800mm From Pivot Pin (kg) 1560
Breakout Force -800mm From Pivot Pin (kg) 1660
Rollback Force at Ground Level -800mm From Pivot Pin (kg) 1890
Reach data
Clearance with bucket dumped 45 deg (mm) N/A
Loader physical data
Arm width (C-C) (mm) 1040
Weight - Front loader (kg) 390
Loader position
Digging Depth (mm) 150
Tractor / Loader physical Data
Tractor PTO HP Range (hp) 50-80
Tractor weight (max)(kg) 4000
Loader Weight (kg) 390
Arm width (C-C) (mm) 1040
* Varies depending on machine and implement
