Features

EXACT CONTROL WITH CENTRAL DISTRIBUTION VALVE

Our centrally-placed valve has many advantages.

It gives the loader exact control and optimal force for heavy-duty tasks

PIVOT PIN COVERS KEEPS THE GREASE INSIDE

Smart details makes the Q-series easy to keep clean. Every pivot pin has a cover that ensures the lubricating grease is contained when for instance pressure washing, keeping the loader and tractor clean.

SAFE CONNECTIONS WITH LOCK & GO®

Our well proven  connect and disconnect system Lock & Go® will save you time without having to compromise on safety.

IMPLEMENT ANGLE INDICATOR

The compact implement angle indicator is easily adjusted for different implements and offer settings for 3 different implements at the same time.

EFFECIENT RESPONSE

The hydraulic system has been substantially improved and boasts around half of the pressure drop compared to our previous loader range.

Q -LINK – PRECISE PARALLEL LINKAGE

Mechanical self-levelling is a safe and convenient option.

ERGONOMIC LOCKING HANDLE

Loaders with manual implement lock comes with our clever and safe Clic-on function that ensures reliable implement locking – every time.

Specifications

Lift heights and bucket angles
Maximum Lift Height - Measured at Pivot Pin (m) 3.79
Maximum Lift Height - Under Level Bucket (m) 3.49
Maximum Dump Angle at Maximum height° (Degrees) 58
Maximum Q Level angle° (Degrees) 58
Maximum Rollback Angle at ground° (Degrees) 48
Loader forces
Lift Capacity to Maximum Height -800mm From Pivot Pin (kg) 1920
Lift Capacity, 1,5m Height -800mm From Pivot Pin (kg) 1940
Breakout Force -800mm From Pivot Pin (kg) 1990
Rollback Force at Ground Level -800mm From Pivot Pin (kg) 3360
Reach data
Clearance with bucket dumped 45 deg (mm) 2820
Loader physical data
Arm width (C-C) (mm) 1040
Weight - Front loader (kg) 575
Loader position
Digging Depth (mm) 160
Tractor / Loader physical Data
Tractor PTO HP Range (hp) 80-140
Tractor weight (max)(kg) 5800
Loader Weight (kg) 575
Arm width (C-C) (mm) 1040
* Varies depending on machine and implement
