- E-Z clean smooth decks are on the center and wings.
- Wing “free float” without movement of wing hydraulic cylinder rod extends cylinder life.
- Gearbox oil sight gauge allows the checking of the oil level in a few seconds.
- PTO driveline holder is standard.
- Wheel spindles are in halves for economy and ease of maintenance.
- A single hydraulic hose is standard for lifting. Two hoses are optional for lifting wings independently of center section.
- Center section cushions are at each axle arm to absorb shocks near the wheels.
- Replaceable full length sideband skids give maximum protection and strength to the sideband.
- Wheel hub cap retainers are standard to prevent loss of cap and hub grease.
- Safety lights for highway travel are standard.
- Full Length Sideband Skids
- Each axle arm on the center section has a rubber cushion to absorb the shock loads near the wheels. Shown with optional dual tires on the center.
- Patented oil sight gauge in all three cutting gearboxes for quick and easy monitoring of oil levels.
|Cutting Width:||12 ft.|
|Cutting Height:||2-inches to 12-inches|
|Tongue Weight:||1,086 lbs.|
|Estimated Total Weight:||3,278 lbs.|
|Tractor h.p. Range@ PTO:||50 to 75|
|Side Band:||1/4 in. x 10 in.|
|Blades:||1/2 in. x 3 in. Hi-Uplift|
|Blade Holder:||Oval Pan|
|PTO Drivelines:||ASAE Cat 4|
|Center & Wing Drivelines:||ASAE Cat 3|
|Wing Flex:||22° Down to 87° up|
|Wing Free Float:||22° down to 25° up|
|Splitter Gearbox Rating:||160 h.p.|
|Cutting Gearbox Rating:||65 h.p.|
|Gearbox Oil Sight Gauge:||Standard|
|Gearbox Warranty:||5 Years|
|Blade Tip Speed @ 540 pto:||14,464 FPM Center/13,930 Wings|
|Cutting Capacity:||1 1/2 in.|
|Axle Pivot Points:||Bushings With Grease Fittings|
|Axle Cushions, Center Section:||Rubber Bumper Near Each Wheel|
|Safety Tow Chain:||Standard|
|Highway Safety Lights:||Standard|
