Features

POWER AND INNOVATION

The Dual High-Performance Hydro-Gear Integrated Drive System provides for reliable, self-contained power and performance. Drives are protected by skid plates from curbs or other obstructions. The brake, engage, electric blade start and control levers are all right together on the control bar. Our unique central lock—locking both transmissions in a single action for ensuring a straight cut — is a Bad Boy exclusive!

STRENGTH AND CUT QUALITY

The heavy-duty, all-steel frame and deck are exactly what you expect from Bad Boy. The deck locks into a consistent cut height with our pull pin system. Handles on deck assists while making any adjustments. The front and rear tires are the largest of any other in this class and makes for better traction and stability, for an even cleaner more manicured cut.

CONTROL AND COMFORT

Our single lever 'rider presence' switch offers safety and convenience to the operator. Paired with the optional Sulky, you’ll be even more comfortable. This Sulky is so unique, it’s patented. The single rear wheel features our EZ-Ride™ technology for smooth, vibration absorbing performance. Adjustable two-position podium height for either walking or riding with sulky.

Specifications

 ENGINE OPTIONS
 Kawasaki  5400 - 603cc Air-Cooled FS600
 Kawasaki  3600/4800 - 603cc Air-Cooled FS541
 DIMENSIONS
 Cutting Width  3600 - 36"
4800 - 48"
5400 - 54"
 Weight  3600 - 607 lbs.
4800 - 672 lbs.
5400 - 727 lbs.
 Overall Height/Length  48"/63"
 Chute Up/Chute Down Width  3600 - 38.5"/50.5"
4800 - 50.5"/62.5"
5400 - 56.5"/68.5"
 FEATURES
 Transmission 3100 Hydro-Gear® 12cc Integrated Transaxle
 Deck Thickness  3/16" Thick Solid Steel
 Cutting Height  3600 - 1"-4.5"
4800/5400 - 1"-5"
 Lift and Height Adjustment  Manual Lift
 Rear Tires/Front Tires  3600 - 21x7-10 / 12x6-5 Smooth
4800/5400 - 21x8-50 Turf / 12x6-5 Smooth
 Fuel  5 Gallons; Unleaded Gasoline
Ground Speed (Forward) Up To 6 mph
