All New 1.5˝ x 3˝ Heavy-Gauge All-Steel Rail backbone.
All New Patented independent cast front iBeam suspension rails.
All New Larger Size, No-Flat Front Tires are standard.
Patented Dual Deck Support Isolators, paired with our new deck wear pad, minimizes damage from side impacts.
All New 3-Link Rear Trailing Arm Suspension — the first and only of its kind in the industry. Matched with front suspension arms, to provide a smoother ride, more consistent tire contact and increased hillside stability.
All New Adjustable Footrest — the first and only of its kind. Can be moved forward or backward to accommodate riders of all sizes!
All New Suspension Seat is fully adjustable to operator weight and height with variable rate suspension, lumbar support and back adjustments from 5° to 15°.
All New Sloped 1/4˝ Deck with 3/8˝ sides. The front deck chamber allows the grass to stand at a more natural, upright position before contact with the cutting blades.
All New Deck Idler Arm and Deck Spring with bearings for consistent belt tension and more consistent cutting speed.
PEER Spindles, made of ductile iron, are 60% stronger than aluminum housings. The optimized seal lip design allows for a maintenance-free spindle, providing longer life.
Dual 16cc Hydro-Gear Pumps with 18ci Parker Wheel Motors,preferred by professionals.
|Cutting Width||6100 - 61"; 7200 - 72"|
|Cutting Height||2" - 6" In 1/3" Increments|
|Blades||6100 - 1/4" x 2 1/2" x 21", High Lift, Heat Treated
7200 - 1/4" x 2 1/2" x 24", High Lift, Heat Treated
|Lift and Height Adjustment||Foot-Assist Manual lift with Dial-Style height adjustment. Optional electric lift|
|Blade Belt||Single V-Belt Spring Tension|
|Anti-Scalp Rollers||6 Total (4 Double-Bracketed Front Wheels, 2 Rear Wheels)|
|Deck Flotation||Floats on (4) 1/4" Deck Hangers|
|Deck Thickness||1/4" Thick Solid Steel With Additional 1/4" Steel Leading Edge And 3/8" Side Trim|
|Gross Horsepower/CC||993cc (37hp) Horizontal Shaft Vanguard® EFI|
|Cylinders||90 Degree V-Twin|
|Maximum Torque||N/A (Vanguard does not release this information)|
|Fuel Requirement||Unleaded Gasoline (87 Octane or higher)|
|Fuel Capacity||13 Gallons|
|Fuel Filter||Replaceable Automotive Type|
|Charging System||20 Amp|
DRIVE SYSTEM SPECIFICATIONS
|Wheel Drive||18 cu. in. High Torque Parker Motors|
|Hydrostatic System Oil||20W50 Motor Oil|
|Hydraulic Filter||25 Micron, Replaceable Spin-On Type, 1 Per Pump|
|Pumps||16cc Hydro-Gear® Pumps With Dual V-Belts From Engine Crankshaft|
|Hydraulic Coolers||Finned Extruded Aluminum Heat Exchangers|
|Weight||6100 - 1,535 lbs.; 7200 - 1,595 lbs.|
Chute Up/Chute Down
|6100 - 62"/75 1/2"; 7200 - 74"/88"|
|Tire to Tire Width||6100 - 59"; 7200 - 59"|
|Tires - Front||13 x 6.0 - 6 Smooth Tread|
|Tires - Rear||26 x 12 - 12 Reaper Tires|
|Steering||Dual Lever Steering, Independent Control|
|Turning Radius||Zero Turn - Zero Degrees, Turns Within Unit Length|
|Ground Speed (forward)||Up To 13 mph|
|Parking Brake||Internal Parking Brake|
