Features
Strength
All New 1.5˝ x 3˝ Heavy-Gauge All-Steel Rail backbone.
All New Patented independent cast front iBeam suspension rails.
All New Larger Size, No-Flat Front Tires are standard.
Patented Dual Deck Support Isolators, paired with our new deck wear pad, minimizes damage from side impacts.
Comfort
All New 3-Link Rear Trailing Arm Suspension — the first and only of its kind in the industry. Matched with front suspension arms, to provide a smoother ride, more consistent tire contact and increased hillside stability.
All New Adjustable Footrest — the first and only of its kind. Can be moved forward or backward to accommodate riders of all sizes!
All New Suspension Seat is fully adjustable to operator weight and height with variable rate suspension, lumbar support and back adjustments from 5° to 15°.
Cut Quality
All New Sloped 1/4˝ Deck with 3/8˝ sides. The front deck chamber allows the grass to stand at a more natural, upright position before contact with the cutting blades.
All New Deck Idler Arm and Deck Spring with bearings for consistent belt tension and more consistent cutting speed.
PEER Spindles, made of ductile iron, are 60% stronger than aluminum housings. The optimized seal lip design allows for a maintenance-free spindle, providing longer life.
Power
Dual 16cc Hydro-Gear Pumps with 18ci Parker Wheel Motors,preferred by professionals.
Specifications
MOWER SPECIFICATIONS |
|
Cutting Width | 6100 - 61"; 7200 - 72" |
Cutting Height | 2" – 6" In 1/3" Increments |
Blades | 6100 - 1/4" x 2 1/2" x 21", High Lift, Heat Treated 7200 - 1/4" x 2 1/2" x 24", High Lift, Heat Treated |
Lift and Height Adjustment | Foot-Assist Manual lift with Dial-Style height adjustment. Optional electric lift |
Blade Belt | Single V-Belt Spring Tension |
Anti-Scalp Rollers | 6 Total (4 Double-Bracketed Front Wheels, 2 Rear Wheels) |
Deck Flotation | Floats on (4) 1/4" Deck Hangers |
Deck Thickness | 1/4" Thick Solid Steel With Additional 1/4" Steel Leading Edge And 3/8" Side Trim |
ENGINE SPECIFICATIONS |
|
Gross Horsepower/CC | 993cc (35hp) Horizontal Shaft Vanguard® |
Cylinders | 90 Degree V-Twin OHV |
Displacement | 993 cc |
Maximum Torque | N/A (Vanguard does not release this information) |
Fuel Requirement | Unleaded Gasoline (87 Octane or higher) |
Fuel Capacity | 13 Gallons |
Fuel Filter | Replaceable Automotive Type |
Cooling System | Air-Cooled |
Ignition | Electronic |
Starter | 12 Volt |
Charging System | 20 Amp |
DRIVE SYSTEM SPECIFICATIONS |
|
Transmission | Dual Hydrostatic |
Pump Drive | - |
Wheel Drive | 18 cu. In. High Torque Parker Motors® |
Hydrostatic System Oil | 20W50 Motor Oil |
Hydraulic Filter | 25 Micron, Replaceable Spin-On Type, 1 Per Pump |
Pumps | 16cc Hydro-Gear® Pumps With Dual V-Belts From Engine Crankshaft |
Hydraulic Coolers | Finned Extruded Aluminum Heat Exchangers |
MOWER DIMENSIONS |
|
Weight | 6100 - 1,535 lbs.; 7200 - 1,595 lbs. |
Overall Height | 51" |
Overall Width Chute Up/Chute Down |
6100 - 62"/75 1/2"; 7200 - 74"/88" |
Overall Length | 91" |
Tire to Tire Width | 6100 - 59"; 7200 - 59" |
Tires - Front | 13 x 6.0 - 6 Smooth Tread |
Tires - Rear | 26 x 12 - 12 Reaper Tires |
Steering | Dual Lever Steering, Independent Control |
Turning Radius | Zero Turn - Zero Degrees, Turns Within Unit Length |
Ground Speed (forward) | Up To 13 mph |
Parking Brake | Internal Parking Brake |
