All New 1.5˝ x 3˝ Heavy-Gauge All-Steel Rail backbone.
All New iBeam Front Rail with steel 1/2˝ front forks.
Patented Dual Deck Support Isolators, paired with our new deck wear pad, minimizes damage from side impacts.
All New Adjustable Footrest — the first and only of its kind. Can be moved forward or backward to accommodate riders of all sizes!
All New Suspension Seat upgrade is available on all models and is fully adjustable with variable rate suspension, lumbar support and back adjustments from 5° to 15°.
All New Sloped 1/4˝ Deck with 3/8˝ sides. The front deck chamber allows the grass to stand at a more natural, upright position before contact with the cutting blades.
All New Deck Idler Arm and Deck Spring with bearings for consistent belt tension and more consistent cutting speed.
PEER Spindles, made of ductile iron, are 60% stronger than aluminum housings. Optimized for a maintenance-free spindle.
High Performance Hydro-Gear 4400 Integrated Drive Systemfor reliable, self-contained power and performance.
|Cutting Width||6100 - 61"; 7200 - 72"|
|Cutting Height||1" – 5" In 1/3" Increments|
|Blades||6100 - 1/4" x 2 1/2" x 21", High Lift, Heat Treated
7200 - 1/4" x 2 1/2" x 24", High Lift, Heat Treated
|Lift and Height Adjustment||Foot-Assist Manual Lift With Dial-Style Height Adjustment. Optional Electric Lift|
|Blade Belt||Single V-Belt Spring Tension|
|Anti-Scalp Rollers||6 Total (4 Double-Bracketed Front Wheels, 2 Rear Wheels)|
|Deck Flotation||Floats On Four 1/4" Deck Hangers|
|Deck Thickness||1/4" Thick Solid Steel With Additional 1/4" Steel Leading Edge And 3/8" Side Trim|
|Gross Horsepower/CC||993cc (36hp) Air-Cooled Vanguard®|
|Maximum Torque||59 ft. lbs. @ 2,600 RPM|
|Fuel Requirement||Unleaded Gasoline (87 Octane or higher)|
|Fuel Capacity||13 Gallons|
|Fuel Filter||Replaceable Automotive Type|
|Charging System||20 Amp|
DRIVE SYSTEM SPECIFICATIONS
|Transmission||Hydro-Gear® ZT-4400 Dual Integrated Hydrostatic Transaxle|
|Pump Drive||Integrated Axial Piston Pump & Motor w/ Gear Reduction|
|Wheel Drive||Integrated with Commercial Grade Gear Reduction|
|Hydrostatic System Oil||20W50 Motor Oil|
|Hydraulic Filter||25 Micron, Replaceable Spin-On|
|Hydraulic Coolers||8" 3,600RPM Cooling Fan; One Per Unit|
|Weight||6100 - 1,325 lbs.; 7200 - 1,375 lbs.|
Chute Up/Chute Down
|6100 - 63 1/2"/75 1/2"; 7200 - 74"/86 1/2"|
|Tire to Tire Width||6100 - 55 1/2"; 7200 - 55 1/2"|
|Tires - Front||13 x 6.5 – 6 Smooth Tread|
|Tires - Rear||24 x 12 - 12 Reaper Tires|
|Steering||Dual Lever Steering, Independent Control|
|Turning Radius||Zero Turn - Zero Degrees, Turns Within Unit Length|
|Ground Speed (forward)||Up To 12 mph|
|Parking Brake||Internal Parking Brake|
