Features
STRENGTH
Classic Bad Boy 2˝ x 2˝ Heavy-Gauge All-Steel Rail backbone.
1/2˝ Front Forks stand up to the toughest environments.
Lower profile frame with curved front rail improves stability on inclines and uneven turf.
Patented Dual Deck Support Isolators minimizes damage to your deck from side impacts.
COMFORT
Smoother steering and tighter, more precise controls with our steering dampening system. Features our fully adjustable handles for exactly the right operator fit.
Premium Comfort Seat is adjustable and cushioned with side and upper back support and also has cushioned arm rests.
PERFORMANCE
Slip in and out of tight places with the 42˝ or 48˝ deck.
Foot-assist deck lift pedal for reliable manual deck operation. Lock in your preferred deck height of up to 4 1/2˝ by simply pushing the pedal and twisting the easy to reach knob. Deck locks tight for a perfect height cut every time.
Solid Steel deck features 7-gauge formed and welded steel with an additional 3/8˝ reinforced edge. The improved baffling system gives greater lift to the grass, producing a cleaner cut and more even discharge.
POWER
High Performance Hydro-Gear 3400 Integrated Drive System for reliable, self-contained power and performance.
Specifications
Mower Specifications | |
---|---|
Cutting Width | 4200 - 42"; 4800 - 48" |
Cutting Height | 1.5" – 4.5" with Deck Height Control System |
Blades | 4200 - 7/32" x 2 1/2" x 14 1/2", High Lift, Heat Treated 4800 - 1/4" x 2 1/2" x 16 1/2", High Lift, Heat Treated |
Lift and Height Adjustment | Foot-Assist Manual lift with Dial-Style height adjustment. Optional electric lift |
Blade Belt | Single V-Belt Spring Tension |
Anti-Scalp Rollers | 4200 - 4 Total 4800 - 4 Total (2 Front, 2 Rear) |
Deck Flotation | Floats On Four 1/4" Deck Hangers |
Deck Thickness | 3/16" Thick Solid Steel |
Engine Specifications | |
---|---|
Gross Horsepower/CC | 810cc Vanguard® |
Cylinders | 90 Degree V-Twin |
Displacement | 810 cc |
Maximum Torque | 42 ft. lbs. @ 2,400 RPM |
Fuel Requirement | Unleaded Gasoline (87 Octane or higher) |
Fuel Capacity | 6.5 Gallons |
Fuel Filter | Replaceable Automotive Type |
Cooling System | Air-Cooled |
Ignition | Electronic |
Starter | 12 Volt |
Charging System | 20 Amp |
Drive System Specifications | |
---|---|
Transmission | Industrial Grade Dual Integrated Hydrostatic Transaxle |
Pump Drive | Integrated Axial Piston Pump & Motor w/Planetary Gear Reduction |
Wheel Drive | Hydro-Gear® Integrated ZT-3400 Series Transaxle |
Hydrostatic System Oil | 20W50 Motor Oil |
Hydraulic Filter | Internal, Replaceable, 1 Per Axle |
Pumps | Hydro-Gear® 12cc Pump |
Hydraulic Coolers | 9" 3,600RPM Cooling Fan; One per unit |
Mower Dimensions | |
---|---|
Weight | 4200 - 990 lbs.; 4800 - 1,005 lbs. |
Overall Height | 49" |
Overall Width Chute Up/Chute Down |
4200 - 47" / 56"; 4800 - 54" / 61" |
Overall Length | 80" |
Tire to Tire Width | 42" |
Tires - Front | 13 x 6.5 – 6 Smooth Tread |
Tires - Rear | 23 x 8.5 - 10 Turf Tread |
Steering | Dual Lever Steering, Independent Control |
Turning Radius | Zero Turn - Zero Degrees, Turns Within Unit Length |
Ground Speed (forward) | Up To 9 mph |
Parking Brake | Internal Wet Disk |
