Classic 2˝ x 2 ˝ heavy-gauge all-steel rail frame backbone.
Curved front rail with 3/8˝ front forks are an industry-leading Bad Boy construction hallmark.
All-steel, all-welded construction throughout.
Smoother steering and tighter, more precise controls with our steering dampening system.
Our seat features more cushion and comfort with cushioned arm rests that can be flipped up and out of the way.
Easy to handle parking brake with 90° angled formed grip is easier to get a handle on.
Ergonomically designed tanks not only hold more fuel, a full 6.5 gallons, but also features lots of deep storage and a cup holder for your favorite beverage.
Solid Steel deck features 7-gauge formed and welded steel with an additional 3/8˝ reinforced edge is heaviest in class. The improved baffling system gives greater lift to the grass, producing a cleaner cut and more even discharge.
DeckDial with deck height pedal locks deck to exact cutting heights from 1.5˝ to 4.5˝ for a consistent, predictable cut. Deck pedal can be adjusted for right or left side operation.
High Performance Hydro-Gear 3100 Integrated Drive System for reliable, self-contained power and performance.
|Cutting Width||5400 - 54"; 6000 - 60"|
|Cutting Height||1.5" – 4.5" with Deck Height Control System|
|Blades||5400 - 1/4" x 2 1/2" x 18 3/4", High Lift, Heat Treated
6000 - 1/4" x 2 1/2" x 20 1/2", High Lift, Heat Treated
|Lift and Height Adjustment||Foot-Assist Manual lift with Dial-Style height adjustment. Optional electric lift|
|Blade Belt||Single V-Belt Spring Tension|
|Anti-Scalp Rollers||5400 - 4 Total (2 Front, 2 Rear)
6000 - 6 Total (4 Front, 2 Rear)
|Deck Flotation||Floats On Four 1/4" Deck Hangers|
|Deck Thickness||3/16" Thick Solid Steel|
|Gross Horsepower/CC||747cc Air-Cooled Kohler® Pro 7000|
|Cylinders||90 Degree V-Twin|
|Maximum Torque||41.3 ft. lbs. @ 2,400 RPM|
|Fuel Requirement||Unleaded Gasoline (87 Octane or higher)|
|Fuel Capacity||6.5 Gallons|
|Fuel Filter||Replaceable In-Line Filter|
|Charging System||16 Amp|
Drive System Specifications
|Transmission||ZT-3100 Hydro-Gear® 10cc Integrated Transaxle|
|Pump Drive||Integrated Axial Piston Pump & Motor w/Gear Reduction|
|Wheel Drive||Integrated with Commercial Grade Gear Reduction|
|Hydrostatic System Oil||20W50 Motor Oil|
|Hydraulic Filter||25 Micron, Replaceable Spin-On Type, 1 Per Axle|
|Pumps||10cc Pump and Motor Integrated In One Unit|
|Hydraulic Coolers||7" Cooling Fan; One per unit|
|Weight||5400 - 823 lbs.; 6000 - 838 lbs.|
Chute Up/Chute Down
|5400 - 58" / 67"; 6000 - 64" / 73"|
|Tire to Tire Width||46"|
|Tires - Front||13 x 6.5 – 6 Smooth Tread|
|Tires - Rear||22 x 11 - 10 Turf Tread|
|Steering||Dual Lever Steering, Independent Control|
|Turning Radius||Zero Turn - Zero Degrees, Turns Within Unit Length|
|Ground Speed (forward)||Up To 7 mph|
|Parking Brake||Internal Parking Brake|
