Features
STRENGTH
Classic 2˝ x 2 ˝ heavy-gauge all-steel rail frame backbone.
Curved front rail with our patented front and rear EZ-Ride suspension system and 1/2˝ front forks are an industry leading Bad Boy construction hallmark.
Built and outfitted commercial-grade tough but perfect for the demanding landowner.
Patented Dual Deck Support Isolators minimizes damage to your deck from side impacts.
COMFORT
Smoother steering and tighter, more precise controls with our steering dampening system. Features our fully adjustable handles for exactly the right operator fit.
Premium Comfort Seat is adjustable and cushioned with side, upper back support and cushioned arm rests.
CUT QUALITY
Solid Steel deck features 7-gauge formed and welded steel with an additional 3/8˝ reinforced edge is heaviest in class. The improved baffling system gives greater lift to the grass, producing a cleaner cut and more even discharge.
DeckDial with deck height pedal locks deck to exact cutting heights from 1.5˝ to 4.5˝ for a consistent, predictable cut. Deck pedal can be adjusted for right or left side operation.
POWER
High Performance Hydro-Gear 3200 Integrated Drive System for reliable, self-contained power and performance.
Specifications
Mower Specifications | |
|---|---|
| Cutting Width | 4800 - 48"; 5400 - 54"; 6000 - 60" |
| Cutting Height | 1.5" – 4.5" with Deck Height Control System |
| Blades | 4800 - 1/4" x 2 1/2" x 16 1/2", High Lift, Heat Treated 5400 - 1/4" x 2 1/2" x 18 3/4", High Lift, Heat Treated 6000 - 1/4" x 2 1/2" x 20 1/2", High Lift, Heat Treated |
| Lift and Height Adjustment | Foot-Assist Manual lift with Dial-Style height adjustment. Optional electric lift |
| Blade Belt | Single V-Belt Spring Tension |
| Anti-Scalp Rollers | 4800 - 4 Total (2 Front, 2 Rear) 5400 - 4 Total (2 Front, 2 Rear) 6000 - 6 Total (4 Front, 2 Rear) |
| Deck Flotation | Floats On Four 1/4" Deck Hangers |
| Deck Thickness | 3/16" Thick Solid Steel |
Engine Specifications | |
|---|---|
| Gross Horsepower/CC | 726cc Air-Cooled Kawasaki® FS |
| Cylinders | V-Twin |
| Displacement | 726 cc |
| Maximum Torque | 40 ft. lbs. @ 2,600 RPM |
| Fuel Requirement | Unleaded Gasoline (87 Octane or higher) |
| Fuel Capacity | 6.5 Gallons |
| Fuel Filter | Replaceable Automotive Type |
| Cooling System | Air-Cooled |
| Ignition | Electronic |
| Starter | 12 Volt |
| Charging System | 20 Amp |
Drive System Specifications | |
|---|---|
| Transmission | Hydro-Gear® ZT-3200 Dual Integrated Hydrostatic Transaxle |
| Pump Drive | Integrated Axial Piston Pump & Motor w/Gear Reduction |
| Wheel Drive | Integrated With Commercial Grade Gear Reduction |
| Hydrostatic System Oil | 20W50 Motor Oil |
| Hydraulic Filter | 25 Micron, Replaceable Spin-On Type, 1 Per Pump |
| Pumps | 10cc Pump And Motor Integrated In One Unit |
| Hydraulic Coolers | 7" RPM Cooling Fan; One per unit |
Mower Dimensions | |
|---|---|
| Weight | 4800 - 862 lbs.; 5400 - 871 lbs.; 6000 - 925 lbs. |
| Overall Height | 49" |
| Overall Width Chute Up/Chute Down |
4800 - 54" / 61"; 5400 - 58" / 67"; 6000 - 64" / 76" |
| Overall Length | 75" |
| Tire to Tire Width | 46 1/2" |
| Tires - Front | 13 x 6.5 – 6 Smooth Tread |
| Tires - Rear | 4800 - 23 x 8.5 - 12 Turf Tread; 5400 - 23 x 10.5 - 12 Turf Tread; 6000 - 23 x 10.5 - 12 Turf Tread |
| Steering | Dual Lever Steering, Independent Control |
| Turning Radius | Zero Turn - Zero Degrees, Turns Within Unit Length |
| Ground Speed (forward) | Up To 9 mph |
| Parking Brake | Internal Parking Brake |
