Classic 2˝ x 2 ˝ heavy-gauge all-steel rail frame backbone.
Curved front rail with 3/8˝ front forks are an industry-leading Bad Boy construction hallmark.
Smoother steering and tighter, more precise controls with our steering dampening system.
Comfort Seat is adjustable and cushioned with side and upper back support.
Flip-up floorboard with rubber mat is a first in this class.
Solid Steel deck features 7-gauge formed and welded steel with an additional 1/4˝ reinforced edge—the heaviest in its class.
DeckDial with deck height pedal locks deck to exact cutting heights from 1.5˝ to 4.5˝ for a consistent, predictable cut. Deck pedal can be adjusted for right or left side operation.
High Performance Integrated Drive Systems for reliable, self-contained power and performance.
|Cutting Height||1.5" – 4.5" with Deck Height Control System|
|Blades||7/32" x 2 1/2" x 14 1/2", High Lift, Heat Treated|
|Lift and Height Adjustment||Foot-Assist Manual lift with Dial-Style height adjustment. Optional electric lift|
|Blade Belt||Single V-Belt Spring Tension|
|Anti-Scalp Rollers||2 Front|
|Deck Flotation||Floats On Four 1/4" Deck Hangers|
|Deck Thickness||3/16" Thick Solid Steel|
|Gross Horsepower/CC||725cc Air-Cooled Kohler® Pro 7000|
|Cylinders||90 Degree V-Twin|
|Maximum Torque||40 ft. lbs. @ 2,600 RPM|
|Fuel Requirement||Unleaded Gasoline (87 Octane or higher)|
|Fuel Capacity||5 Gallons|
|Fuel Filter||Replaceable Automotive Type|
|Charging System||16 Amp|
Drive System Specifications
|Transmission||Dual Integrated Hydrostatic Transaxle|
|Pump Drive||Integrated Axial Piston Pump & Motor w/Gear Reduction|
|Wheel Drive||Integrated with Gear Reduction|
|Hydrostatic System Oil||20W50 Motor Oil|
|Pumps||EZT Integrated Unit|
|Hydraulic Coolers||7" Cooling Fan Per Unit|
Chute Up/Chute Down
|4200 - 47" / 56"|
|Tire to Tire Width||41"|
|Tires - Front||11 x 6.0 – 5 Smooth Tread|
|Tires - Rear||18 x 8.5 - 8 Turf Tread|
|Steering||Dual Lever Steering, Independent Control|
|Turning Radius||Zero Turn - Zero Degrees, Turns Within Unit Length|
|Ground Speed (forward)||Up To 6 mph|
|Parking Brake||External Cogg Brake|
