Features
STRENGTH
Classic 2˝ x 2 ˝ heavy-gauge all-steel rail frame backbone.
Curved front rail with 3/8˝ front forks are an industry-leading Bad Boy construction hallmark.
COMFORT
Smoother steering and tighter, more precise controls with our steering dampening system.
Comfort Seat is adjustable and cushioned with side and upper back support.
Flip-up floorboard with rubber mat is a first in this class.
CUT QUALITY
Solid Steel deck features 7-gauge formed and welded steel with an additional 1/4˝ reinforced edge—the heaviest in its class.
DeckDial with deck height pedal locks deck to exact cutting heights from 1.5˝ to 4.5˝ for a consistent, predictable cut. Deck pedal can be adjusted for right or left side operation.
POWER
High Performance Integrated Drive Systems for reliable, self-contained power and performance.
Specifications
Mower Specifications | |
|---|---|
| Cutting Width | 4800 - 48"; 5400 - 54" |
| Cutting Height | 1.5" – 4.5" with Deck Height Control System |
| Blades | 4800 - 7/32" x 2 1/2" x 16 1/2", High Lift, Heat Treated 5400 - 7/32" x 2 1/2" x 18 1/2", High Lift, Heat Treated |
| Lift and Height Adjustment | Foot-Assist Manual lift with Dial-Style height adjustment. Optional electric lift |
| Blade Belt | Single V-Belt Spring Tension |
| Anti-Scalp Rollers | 2 Front |
| Deck Flotation | Floats On Four 1/4" Deck Hangers |
| Deck Thickness | 3/16" Thick Solid Steel |
Engine Specifications | |
|---|---|
| Gross Horsepower/CC | 726cc Kawasaki® FR651 |
| Cylinders | 90 Degree V-Twin |
| Displacement | 726 cc |
| Maximum Torque | 40 ft. lbs. @ 2,600 RPM |
| Fuel Requirement | Unleaded Gasoline (87 Octane or higher) |
| Fuel Capacity | 5 Gallons |
| Fuel Filter | Replaceable Automotive Type |
| Cooling System | Air-Cooled |
| Ignition | Electronic |
| Starter | 12 Volt |
| Charging System | 16 Amp |
Drive System Specifications | |
|---|---|
| Transmission | Dual Integrated Hydrostatic Transaxle |
| Pump Drive | Integrated Axial Piston Pump & Motoro w/Gear Reduction |
| Wheel Drive | Integrated with Gear Reduction |
| Hydrostatic System Oil | 20W50 Motor Oil |
| Hydraulic Filter | - |
| Pumps | EZT Integrated Unit |
| Hydraulic Coolers | 7" Cooling Fan per Unit |
Mower Dimensions | |
|---|---|
| Weight | 4800 - 661 lbs; 5400 - 686 lbs. |
| Overall Height | 42" |
| Overall Width Chute Up/Chute Down |
4800 - 54" / 61";; 5400 - 58" / 67" |
| Overall Length | 76" |
| Tire to Tire Width | 46" |
| Tires - Front | 11 x 6.0 – 5 Smooth Tread |
| Tires - Rear | 18 x 9.5 - 8 Turf Tread |
| Steering | Dual Lever Steering, Independent Control |
| Turning Radius | Zero Turn - Zero Degrees, Turns Within Unit Length |
| Ground Speed (forward) | Up To 6 mph |
| Parking Brake | External Cogg Brake |
