Premium Grammer Suspension Seat
Fully adjustable to operator weight and height, this seat offers variable suspension, lumbar support and back angle adjustments from 5º to 15º.
SteerTek Precision Drive
With self-lubricating bushings and extremely high-tolerance milled construction, our SteerTek drive system provides the most nimble, fluid, responsive and agile drive system around.
Patented front and rear independent compression shock suppression allows our mower to absorb the ground around for a more comfortable, all-day workload. It also allows the deck to glide more smoothly for a better, more manicured cut.
With Adjustable front leading edge, 5.5" depth and a baffling system to create more lift for greater discharge and cleaner cut, it blows all other decks away.
Swing-Away Design Access
Quick and easy access to virtually every serviceable part of the Diesel makes this patented feature an open and shut case for Bad Boy Mowers.
Dual Fuel Tanks
Hold a total of 18 Gallons of fuel for all-day, non-stop operation.
Separate Hydraulic Tanks and Wheel Motors Pros Demand
Dual Hydraulic tanks and dual individual drive motors for the power and performance professionals demand. Our hydraulic systems, from hoses to tanks, are bigger and more robust to run cooler and provide all the power and speed you'll ever need.
|Cutting Width||6100 - 61"|
|Cutting Height||1.5" - 5" with Deck Height Control System|
|Blades||6100 - 1/4" x 2 1/2" x 21", High Lift, Heat Treated|
|Lift and Height Adjustment||Foot-Assist Manual and Electric Actuator|
|Blade Belt||Single V-Belt Spring Tension|
|Anti-Scalp Rollers||6 Total (4 Front, 2 Rear)|
|Deck Flotation||Floats On (4) 1/4" Deck Hangers|
|Deck Thickness||1/4" Thick Solid Steel|
|Gross Horsepower/cc||1100cc Caterpillar Diesel LC|
|Maximum Torque||70 ft. lbs. @ 3,400 RPM|
|Fuel Capacity||18 Gallons|
|Charging System||20 Amp|
|Drive System Specifications|
|Pump Drive||16cc Hydro-Gear V-Belt From Engine Crankshaft|
|Wheel Drive||18 cu. in. High Torque Parker Motors|
|Hydrostatic System Oil||20W50 Motor Oil|
|Hydraulic Filter||25 Micron, Replaceable Spin-On Type, 1 Per Pump|
|Pumps (2)||Hydro-Gear 16cc Pump|
|Hydraulic Coolers (2)||System Designed With 2 Coolers For Lower Temperatures|
|Weight||6100 - 1,607 lbs.|
Chute Up/Chute Down
|64 1/2" / 74"|
|Tire to Tire Width||6100 - 57"|
|Tires - Front||13 x 6.5 - 6 Smooth Tread|
|Tires - Rear||26 x 12 - 12 Turf Tread|
|Steering||Dual Lever Steering, Independent Control|
|Turning Radius||Zero Turn - Zero Degrees, Turns Within Unit Length|
|Ground Speed (forward)||Up To 12 mph|
|Parking Brake||Disk Brakes|
