Features
Skid Plates: Replaceable 1/4" steel sleds for bearing the brunt as the first line of abuse.
Gearbox: Produce ripping fast blade speeds with slip clutch or shear pin clutch options.
PTO Cradle: Keeps PTO shaft from laying on the ground when stored.
Pivot Locking Top: Makes attaching cutter easier to connect at the top hitch pin.
Ride Along Storage: Instructions or other documents are stored protected on deck.
Rear Skid Plates: Protects the deck from damage when backing into tight areas or around trees.
Specifications
| Category | 4' Bad Boy Cutter |
| Gear Box | 40hp heavy duty |
| Gear Box Mount | 3/8" Steel |
| Deck Thickness | 10 Gauge Solid Welded |
| Skirt Thickness | 10 gauge steel |
| Skid Shoes | 1/4'' Replaceable |
| Lift Attachment Brackets | 1/2" Solid Welded |
| Tail Wheel Arms | 2-1/2˝x2-1/2˝x.180" designed to withstand rear tractor wheel lift off |
| Tail Wheel | 4” x 15” Puncture Resistant Bushing Style |
| Stump Jumper | 12 splined, Standard duty, Pan style |
| Warranty | 3 year limited on gear box 2 year limited on deck |
| Weight | 650 Lbs |
| Length (Including Tailwheel) | 88˝ |
| Total Width | 53 1/2˝ |
| Overall Height | 36 1/2˝ |
| Deck Height | 7˝ |
| Cut Range | 2˝- 10˝ |
| PTO Drive Shaft | Series 4 shear bolt or series 4 slip clutch |
| Blades | 1/2˝ x 3˝ |
| Tractor Range | 24-40 Hp |
| Cutting Capacity | 2˝ Diameter |
| Blade Tip Speed | 13,093 feet / minute |
| 3-Point Hitch | category 1 |
| Blade Spindle | 1 |
| Tractor PTO RPM | 540 |
