Power & Productivity
Muscle to Get the Job Done
CASE skid steer loaders are designed to dominate. Whether you’re up against tough digging, loading, pushing, or grading, these skid steers deliver overall best-in-class performance and breakout force. After all, you deserve a machine that works as hard as you do.
Need to run your loader longer, stronger, and more profitably? No problem with CASE’s heavy-duty rotational force—get up to 282 lb.·ft. (383 N·m) at 1,400 RPM—more power than ever before.
With more than more than 9,500 lbs (42.3 kN) of breakout force, CASE skid steer loaders provide you with more strength to lift and move, so you can do more each day.
Optional Auxiliary Hydraulic Packages
CASE skid steer loaders offer three different optional auxiliary hydraulic packages: standard, high-flow and enhanced high-flow. They also offer secondary auxiliary hydraulics for applications requiring multiple hydraulic movements simultaneously.
Powerstance for Steady Strength
A wheelbase that’s up to 21% longer gives you stability you can feel. The improved weight distribution enables you to lift larger loads and reduces control jerking, back jolting and load-spilling bounce when hauling. Clear curbs easier, retain more material and experience a faster, more comfortable ride.
Visibility, Comfort and Control
Climb in the cab and you’ll feel the difference. We know your cab is your workplace, so we designed an operating environment that delivers more room, visibility, comfort and control.
Easily see what’s all around you with industry leading visibility and standard side lighting, ensuring skid steer operators can maneuver quicker and more confidently at any time – that’s safe operation.
Ultimate Cab Comfort
A comfortable operator is a productive and happy operator. At nearly three feet wide, CASE skid steer loaders offer one of the largest ROPS/FOPS-certified cabs in the industry. It’s fully sealed and pressurized to reduce noise, dust and fumes—and comes with an optional radio and upgraded climate control system.
EZ-EH controls: Quickly switch between personalized settings for speed and control customization; program up to nine different presets to recall operator settings for different jobs and different operators - all at the touch of a button. There’s also an intuitive lockout menu and rocker switch to easily alternate between CASE “H” and “ISO” patterns.
Ride Control™: Just push a button to automatically steady the loader arm when traveling at elevated speeds and the machine automatically compensates with greater shock absorption and reduced loader arm bounce, so you can work faster than ever without spilling your load.
|Gross hp (kW)||48.8 (36.4) @ 2800 RPM|
|Net hp (kW)||45.8 (34.1)|
|Peak Torque - lb.·ft. (N·m)||105.5 (143)|
|Displacement - in.³ (L)||135.2 (2.2)|
|Emissions Certification||Tier 4 Final (DOC, DPF)|
|Rated Operating Capacity - ROC 50% - lb. (kg)||1,300 (590)|
|Tipping Load - lb. (kg)||2,600 (1 179)|
|Bucket Breakout Force - lb. (kN)||4,180 (18.6)|
|Standard Aux. Hydraulics - gpm (L/min)||17.5 (66.2)|
|High-Flow Aux. Hydraulics - gpm (L/min)||—|
|Operating Weight - lb. (kg)||5,070 (2 300)|
|Height to Bucket Hinge Pin||112.0 in (2.85 m)|
|Dump Height with Low-Profile Bucket**||84.8 in (2.15 m)|
|Height to Top of ROPS||75.5 in (1.92 m)|
|Overall Length with Low-Profile Bucket||125 in (3.18 m)|
|Over-the-Tire Width with Spec. Tires||59.8 in (1.52 m)|
