| Model | 2012-38HCF-94 |
| Approximate Weight - Without Weeding Disc | 7,141 lbs. (3,239 kg) |
| Approximate Weight - With Weeding Disc | 8,171 lbs. (3,706 kg) |
| Number of Rows | 12 |
| Row Spacing | 38 in. (965 mm) |
| Transport Width | 23 ft. 0 in. (7.0 m) |
| Transport Height | 9 ft. 10 in. (3.0 m) |
| Frame | 7 in. x 7 in. x 0.375 in. (178 x 178 x 9.5 mm) |
| Frame Construction | Laser Cut/Matchcut Components, Robotically Welded |
| Three-Point Hitch | Cat. III |
| Hitch Type | Bolt-On Hitch Weldments |
| Gang Frame | 6 in. x 4 in. x 0.25 in. (152 x 102 x 6.35 mm) |
| Gang Coulter | 20 in. (508 mm) Adjustable Coulter |
| Gang Gauge Wheels | Adjustable Fork Mounted |
| Gauge Wheel Tires | 4.6 in. x 16 in. (117 x 406 mm) Hard Rubber |
| Gang Shank Sweeps | 24 in. (610 mm) Penetrator |
| Depth of Operation | Adjustable |
| Cut Angle | 11, 15, 19 and 23 Degrees |
| Weeding Discs | 14 in. (356 mm) |
| Weeding Disc Bearings | Triple Lip Sealed Roller Bearings |
| Safety Warning Lights and SMV Emblem | Standard |
| Powder Coat Paint, Yellow | Standard |
| Penetrator Sweep (18 in.) | N/A |
| Flat Sweep (24 in.) | Optional |
| Lift Assist Wheel Assembly | Optional |
| Ridgers (4 in. ) | Optional |
| Ridgers (8 in.) | Optional |
| Anhydrous Knife Assembly | Optional |
| Liquid Fertilizer Spray Attachment | Optional |
| Horsepower Requirements | Not Published |
| Specifications subject to change with or without notice. |
