POWER AND VERSATILITY
The mid PTO, independent rear PTO, 9.2-gpm hydraulics and 3-point hitch mean you can handle a variety of implements for just about anything on your to-do list.
EASE AND COMFORT
You operate in confidence and comfort with unmatched Boomer™ visibility and natural controls.
You get the peace of mind of New Holland’s FREE Boomer Guard6 Limited Warranty that includes 2 years of “bumper-to-bumper” coverage plus an extra 4 years of powertrain protection.
MORE POWER WORKING FOR YOU
For dependability you can count on, Boomer™ 24 compact tractors featuring powerful Mitsubishi diesel engines deliver 24 horsepower. What's more, the majority of the gross engine horsepower gets turned into usable power at the PTO to run a variety of implements thanks to an ultra-efficient Tier 4 driveline.
Clean Tier 4 final Compliant engines
3-cylinder engines meet Tier 4 Final regulations without the need for additional fluids or hardware. The Boomer™ 24 will run clean all day long with no extra operator input. They run clean - automatically.
FEWER FILL-UPS TO SLOW YOU DOWN
How far will you go with one of the largest fuel tanks on the market? Fill up the productivity-boosting 6.6-gallon, hood -mounted fuel tank and see for yourself. It's sure to last all day long.
WELL-EQUIPPED FOR INCLEMENT WEATHER
To ensure fast starts in cold weather, Boomer™ 24 compact tractors come equipped with a quick-heating glow plug package and a heavy-duty 560 CCA battery that provides plenty of cranking power.
MADE TO ACCOMMODATE MORE
Superior battery charging and the capability to handle the higher demand of additional electrical accessories provided by a 50-amp alternator.
NO GEARS TO GET IN YOUR WAY
Driving a tractor has never been so easy; thanks to a high-performance, two-range dual-pedal hydrostatic transmission that eliminates the need for gears or clutching. Now you can control the exact speed you want for each task and shuttle more easily when mowing or doing loader work using the new dual forward and reverse foot pedals to propel the tractor.
MORE TRACTION TO TAKE ON MORE TASKS
To help you work more efficiently, four-wheel drive (4WD) comes standard on Boomer™ 24 compact tractors. Simply use the lever on the left fender to shift from 2WD to 4WD when you need some extra traction.
CRUISE THROUGH TASKS
Give your right foot a rest. Select and maintain a constant working speed with the standard cruise control. It really comes in handy for mowing larger properties and transporting your tractor from one location to another.
TWO RANGES THAT RUN THE GAMUT
Use the left-hand fender control pod to select the proper range for the task:
• Blowing snow
• Heavy mowing
• Loader work
• Light mowing
• Moving from job to job
|Gross horsepower, hp (kw)||24.4 (18.2)|
|Rated Speed (rpm)||2700|
|Type||3-cylinder, diesel Tier 4|
|Displacement, cu. in. (L)||80.4 (1.3)|
|Air Cleaner||Single replaceable dry element|
|Fuel Tank, gal (L)||6.6 (25)|
|PTO||Standard rear and mid PTO|
|PTO HP (HST), hp (kw)||18.5 (13.8)|
|PTO speed (rpm)||540 rear/2000 mid PTO|
|PTO Type||Electro-hydraulic engaged; independent|
|Type, Mechanical/hydrostatic||HST+2 range|
|Maximum forward speed, HST - mph (kph), R4||11.3 (18.6)|
|Rear diff. lock engagement||Mechanical/foot|
|Brake type||Mechanical/wet, multi disc|
|Implement hydraulic flow, gpm (lpm)||6.7 (25.5)|
|Steering hydraulic flow, gal. (lpm)||2.9 (11)|
|Remote valves||Optional DIA|
|3-point lift capacity @ ball ends, gal. (lpm)||1433 (650)|
|3-point linkage category||1|
|Wheel base, in. (cm)||59 (150)|
|Length, in. (cm)||103.6 (263.2)|
|Height (ROPS), in. (cm) 85.5 (217.3)||85.5 (217.3)|
|Width, in. (cm)||49.1 (124.7)|
|Weight (HST), lbs. (kg)||1708 (775)|
|Tire choice||R3 turf tread or R4 industrial tread|
