Reduced-Emission Engine Technology - Caring for Nature
The STIHL Inc. “Caring for Nature” seal identifies its powered products that are more environmentally conscious, producing zero or low exhaust emissions. STIHL Inc. defines “low exhaust emissions” as being cleaner than EPA and/or CARB exhaust emission standards.
Quick Chain Adjuster (QCA) (B)
The Quick Chain Adjuster (QCA) (B) allows the user to adjust the tension of the chain without the use of tools. This allows for easy chain adjustment.
STIHL Quickstop® Plus (Q) - an additional chain braking feature
STIHL offers an additional, manually-activated chain brake on some models. This system is designed to engage when the operator’s right hand completely releases the rear handle, stopping the chain within one second. Available on some models.
STIHL chainsaws are equipped with a chain stopping system designed to reduce the risk of injury in certain kickback situations. It is called a STIHL Quickstop® chain brake. The STIHL Quickstop® chain brake is designed to stop the rotation of the chain if activated by the operator’s hand or by inertia if the saw kicks back with sufficient force. In some working positions, the STIHL Quickstop® chain brake can be activated by inertia, stopping the chain within fractions of a second.
|MSE 170 C-BQ Specifications - Occasional and Professional Use|
|ENGINE POWER||1.7 kW (14.2 amps)|
|POWERHEAD WEIGHT||3.8 kg (8.4 lbs.)|
|GUIDE BAR LENGTHS* (Recommended ranges)||30 to 45 cm (12" to 16")|
|CHAIN OIL CAPACITY||200 cc (6.8 oz.)|
|OILOMATIC® CHAIN||3/8" PM3|
|VOLTAGE||120 volt (60 Hz)|
