Our innovative blade design makes it easy to go from mulching to bagging. And vice versa.
Just engage and go, at infinitely variable speeds up to 4.2 mph. Its simple operation makes the S-Series a great mower for training new employees.
The Exmark Signature Cut
The cutting deck is a full five inches deep, delivering a consistently great cut whether you’re bagging or mulching.
Easy On/Off Bag Design
Easy on/off bag design eliminates the need for levers and doors. The top fill feature allows the operator to check how full the bag is during operation.
Patented Front Height Adjustment
Innovative, simple and built to last, our patented front height adjustment eliminates the need for pivot-style adjusters. The single-point rear height adjustment allows the operator to quickly change the cutting height.
2.5 bushel capacity
|Drive Tires||9" x 2.5", semi-pneumatic.|
|Safety Package||Zone start|
|Speed||0.0 mph to 4.2 mph (6.6 kmph) forward.|
|Engine Speed||3,300 rpm|
|Air Filter||Dual element air cleaner|
|Drive Description||Self-propelled; rear-wheel gear-driven.|
|Fuel Capacity||2 quart integral fuel tank|
|Fuel Type||Gas Carbureted|
|Deck Style Description||Fixed deck, Rear -discharge bagger standard with option to mulch.|
|Bag Capacity||2.5 bushels (20 gallons).|
|Deck Construction||5" deep, 1/4"-thick die-cast aluminum.|
|Deck Style||Fixed Deck|
|Width / Cutting Deck||21"|
|Cutting Heights||1.0" (2.5 cm) to 4.5" (11.4 cm) in 0.5" (1.3 cm) increments.|
|Blades||1 Blade at 20.5" Length|
|Blade Tip Speed||Approximately 18,500 fpm.|
|Width||22 in. (55.9 cm)|
|Length||62 in. (157.5 cm)|
|Height||38 in. (96.5 cm)|
