Power & Productivity
Muscle to Get the Job Done
CASE compact track loaders are designed to dominate. Whether you’re up against tough digging, loading, pushing, or grading, these mini track loaders can help you conquer just about any job. After all, you deserve a machine that works as hard as you do.
Need to run your loader longer, stronger, and more profitably? No problem with CASE’s heavy-duty rotational force—get up to 282 lb.·ft. (383 N·m) at 1,400 RPM—more power than ever before.
With more than more than 8,700 lbs (38.7 kN) of breakout force, CASE compact track loaders provide you with more strength to lift and move, so you can do more each day.
Optional Auxiliary Hydraulic Packages
CASE compact track loaders offer three different optional auxiliary hydraulic packages: standard, high-flow and enhanced high-flow. They also offer secondary auxiliary hydraulics for applications requiring multiple hydraulic movements simultaneously.
Traction When and Where it's Needed
Our dozer-style undercarriage is engineered to hold fast on steep slopes and take command of muddy or sandy terrain.
- Rigid track frame with fewer moving parts.
- More durable and easier to maintain than suspension track systems.
- New roller and idler technology reduces maintenance costs and increases undercarriage life.
- Narrow chassis width makes it easy to load and unload on trailers.
Visibility, Comfort and Control
Climb in the cab and you’ll feel the difference. We know your cab is your workplace, so we designed an operating environment that delivers more room, visibility, comfort and control.
Easily see what’s all around you with industry leading visibility and standard side lighting, ensuring operators can maneuver quicker and more confidently at any time – that’s safe operation.
Ultimate Cab Comfort
A comfortable operator is a productive and happy operator. At nearly three feet wide, CASE compact track loaders offer one of the largest ROPS/FOPS-certified cabs in the industry. It’s fully sealed and pressurized to reduce noise, dust and fumes—and comes with an optional radio and upgraded climate control system.
EZ-EH controls: Quickly switch between personalized settings for speed and control customization; program up to nine different presets to recall operator settings for different jobs and different operators - all at the touch of a button. There’s also an intuitive lockout menu and rocker switch to easily alternate between CASE “H” and “ISO” patterns.
Ride Control™: Just push a button to automatically steady the loader arm when traveling at elevated speeds and the machine automatically compensates with greater shock absorption and reduced loader arm bounce, so you can work faster than ever without spilling your load.
|Engine||FPT F5HFL463 A*F001|
|Gross Horsepower–hp (kW)||74 (55)|
|Net Horsepower –hp (kW)||68 (51)|
|Peak Torque–lb ft (Nm)||232 (314)|
|Displacement/Cylinders– in³ (L)||207 (3.4)|
|Emissions Certification* Solutions||Tier 4 Final Certified (CEGR, DOC, PM Catalyst)|
|Rated Operating Capacity (ROC) 35%– lb (kg)||1,890 (860)|
|Rated Operating Capacity (ROC) 50%–lb (kg)||2,700 (1 225)|
|Tipping Load– lb (kg)||5,400 (2 449)|
|Bucket Breakout Force– lb (kN)||7,270 (32.3)|
|Standard Auxiliary Hydraulics–gpm (L/min)||24.2 (91.5)|
|High-Flow Auxiliary Hydraulics–gpm (L/min)||32.4 (122.6)|
|Operating Weight –lb (kg)||8,270 (3 750)|
|Height to Bucket Hinge Pin||123.0 in (3.12 m)|
|Dump Height with Foundry/ Excavating Bucket||98.2 in (2.50 m)|
|Height to Top of ROPS||78.7 in (1.99 m)|
|Overall Length with Foundry/ Excavating Bucket||129.6 in (3.29 m)|
|Track Width||12.6 in (3.20 m)|
