Features



  • Double C channel loader arm for structural strength and streamlined appearance.
  • Reinforcements between the cross tube and loader arm for improved visibility and longer service life.
  • Integrated Park Stands for quick connect and disconnect.
  • Pin lock system for lubrication, strength in wear areas and protection from contaminants.
  • Sub frame strength with large bearing surface for longer loader life.
  • Quick Connect System for improved efficiency.
  • Compact bucket level indicator for ease of monitoring bucket position and recued chance for damage.

Specifications

  • Lift Capacity Max Height @ Pivot Pins: 2,046 lb (930 kg)
  • Boom Breakout Force @ Pivot Pins: 5,214 lb (23.2 kg)
  • Bucket Rollback Force @ Max Height: 3,146 lb (14 kg)
